1) TH- 75/90 PS Foam Sheet Extrusion Line
|
Components:
|
|
|
A.Mixer |
|
|
Hopper Capacity |
100 kg/ hopper (controlled by time relay) |
|
Motor |
1 set, 4-pole, 3TH |
|
B. Automatic Feeding System |
|
|
Automatic Self-control System |
|
|
Motor |
1 set, 6-pole, 1.5TH |
|
C. NO.1 Extruder
|
|
|
Screw Diameter |
Φ75mm |
|
Screw Material: |
38CrMoAlA adopt Nitrogenous treatment |
|
Barrel material
|
38CrMoAlA adopt Nitrogenous treatment
|
|
Motor power:
|
37TH
|
|
Heating zones: |
6 zones |
|
High pressure Butane Pump: |
1 set (1 motor 2.2TH ) |
|
Digital Pressure Gauge: |
1 pc |
|
Fully-automatic Hydraulic filter changer: |
1 set (1 motor 5.5TH ) |
|
Electrical Cabinet: |
1 set |
|
D. NO.2 extruder |
|
|
Screw Diameter: |
Φ90mm |
|
Material |
38CrMoAlA adopt Nitrogenous treatment |
|
Barrel material |
38CrMoAlA adopt Nitrogenous treatment |
|
Motor power: |
37TH |
|
Heating zones |
6zones |
|
Electrical Control Cabinet |
1set |
|
Pressure gauge |
1pc |
|
Head mold: |
1 set |
|
Motor |
control by frequency exchanger |
|
E. Cooling System
|
|
|
Hollowness water circulation cooling |
1 set, as the dimensions by the customers |
|
Cooling method: |
Automatic control cooling |
|
Cooling and fixing: |
with cutting knife 1 set |
|
F. Hauling-off System
|
|
|
Rubber Roller |
3 pcs, (according customer’s requirment) |
|
Traction Speed |
|
|
Motor |
1x 4-pole, 3TH (controlled by frequency changer) |
|
Counter |
1pc |
|
Alarm system |
1set |
|
Haul-off type |
run in S route by self-friction |
|
G. Winding Device |
|
|
Winding Pneumatic Shaft |
2 pcs (according customer’s requirment) |
|
Torque motor |
2sets |
|
Turbine Reducer |
2sets |
|
Static Electricity Eliminator |
1set |
|
Central height |
1000mm |
|
H. Weight |
6T |
