IA. Φ55mm Extruder 1set
1. Screw:
◇ Diameter: 55mm
◇ L/D: 28:1
◇ Material: Professional 38CrMoAlA
◇ Screw heat treatment: Nitrided and polished Cr plated
2. Barrel:
◇ Material: Professional 38CrMoAlA
◇ Inner surface treatment Nitrided and polished Cr plated
◇ Barrel cover: Stainless steel
3. Speed reducer (gear box):
◇ Gearbox material: Alloy steel (40CrMnMo)
◇ Gear type: Inclined gear
◇ Gear material: 20CrMnTi (hard gear, wearable treatment)
◇ Shaft material: 40Cr
◇ Lubrication system: Pressure lubrication
4. Controlling system:
◇ Electric equipments cabinet: 1Unit
◇ Controlling type: Frequency inverter
◇ Heating zone: 5zones（Stainless steel heat band）
◇ Barrel cooling zone: 3 zones
◇ Cooling system: Powerful blower
◇ Controlling power: 15KW
B. Extruding mould 1set
C. 5 meters stainless steel cooling tank 1set
1. Water cooling tank material: Stainless steel
2. Water tank frame: 1 unit.
D. Four-wheel haul-off machine: 1set
1.Motor power: 1.5 kw.
2. Controlling type: Frequency inverter
3. Meter counter: 1set
E. Servo cutter 1set
1. Control way: Servo control
2. Cutting speed: Adjustable
